Specifications
0.5～1.5mm2(22～16) Imax=10A
Item No. | Thickness | Dimension(mm) | Color | ||||
bΦ | F | DΦ | dΦ | L | |||
FPD1.25-156 | 0.4 | 4.0 | 13.0 | 2.7 | 1.7 | 24.5 | Red |
1.5～2.5mm2(16～14) Imax=15A
Item No. | Thickness | Dimension(mm) | Color | ||||
bΦ | F | DΦ | dΦ | L | |||
FPD2-156 | 0.4 | 4.0 | 6.3 | 3.3 | 2.3 | 24.5 | Blue |
FPD2-195 | 0.4 | 5.0 | 7.0 | 3.3 | 2.3 | 24.5 | |
4～6mm2(12～10) Imax=24A
Item No. | Thickness | Dimension(mm) | Color | ||||
bΦ | F | DΦ | dΦ | L | |||
FPD5.5-195 | 0.4 | 5.0 | 7.0 | 4.5 | 3.4 | 29.5 | Yellow |
