Construction & Features
Material：PE(white, grey), elasticity and shock resisting.
Inserting type, nail attached in clips, save time and cast.
Specifications
Item No. | H(mm) | Circle Path | Nail(mm) | Color |
NCC-C-4mm | 5.3 | 4.0 | 1.7×14 | White |
NCC-C-5mm | 6.3 | 5.0 | 1.7×14 | |
NCC-C-6mm | 7.4 | 6.0 | 1.85×16 | |
NCC-C-7mm | 8.4 | 7.0 | 1.85×18 | |
NCC-C-8mm | 9.4 | 8.0 | 1.95×19 | |
NCC-C-9mm | 10.4 | 9.0 | 2.05×22 | |
NCC-C-10mm | 11.4 | 10.0 | 2.20×23 | |
NCC-C-12mm | 13.4 | 12.0 | 2.20×25 | |
NCC-C-14mm | 16.4 | 14.0 | 2.35×30 | |
NCC-C-16mm | 19.0 | 16.0 | 2.35×32 | |
NCC-C-18mm | 19.7 | 18.0 | 2.6×38 | |
NCC-C-20mm | 22.2 | 20.0 | 2.7×40 | |
NCC-C-22mm | 25.0 | 22.0 | 2.9×43 | |
NCC-C-25mm | 27.7 | 25.0 | 3.1×50 | |
NCC-C-30mm | 33.1 | 30.0 | 3.5×55 | |
NCC-C-32mm | 35.6 | 32.0 | 3.5×55 | |
NCC-C-35mm | 36.6 | 35.0 | 3.5×60 | |
NCC-C-40mm | 45.2 | 40.0 | 3.5×65 |
Item No. | H(mm) | A | B | Nail(mm) | Packing |
NCC-F-4mm | 6.0 | 3.8 | 4 | 1.7×14 | 100PCS |
NCC-F-5mm | 6.0 | 3.8 | 5 | 1.7×14 | |
NCC-F-6mm | 6.5 | 4.1 | 6 | 1.7×16 | |
NCC-F-7mm | 7.0 | 4.7 | 7 | 1.9×16 | |
NCC-F-8mm | 7.5 | 5.0 | 8 | 2.1×19 | |
NCC-F-9mm | 8.2 | 5.4 | 9 | 2.1×20 | |
NCC-F-10mm | 8.6 | 5.7 | 10 | 2.3×21 | |
NCC-F-12mm | 9.0 | 6.1 | 12 | 2.3×23 | |
NCC-F-14mm | 11.0 | 8.0 | 14 | 2.3×25 | |
NCC-F-18mm | 12.5 | 10 | 18 | 2.6×27 |
