Frame(A)

100

250

630

1600

3200

Pole Number

3/4

Conventional Thermal Current

63A

100A

160-3200A

Rated Insulating Voltage

690V

800V

Rated Impulse Withstand Voltage

8KV

Rated Working Voltage

400V AC

Rated Working Current(A)

16

20

25

32

40

50

63

80

100

125

160

250

400

630

800

1000

1250

1600

2000

2500

3200

Use Category

AC-33B

AC-33iB

Rated Short-time Withstand Current

5kA/30ms

10kA/60ms

12.6kA/60ms

32kA/60ms

Transfer Time

2.5s

0.6s

1.2s

1.8s

2.4s

Control Voltage

24/48/110V DC, 220V AC

Motor Rated Power

Start

20W

325W

355W

400W

440W

600W

Normal

62W

74W

90W

98W

120W
